Trying to plot a grid of mosaic plots using Seaborn's FacetGrid and statsmodels' mosaic and not quite making it.
Example dataset:
import pandas as pd import numpy as np import seaborn as sns import matplotlib.pyplot as plt from statsmodels.graphics.mosaicplot import mosaic index = [i for j in [[k] * 6 for k in range(4)] for i in j] gender = ['male', 'male', 'male', 'female', 'female', 'female'] * 4 pet = np.random.choice(['cat', 'dog'], 24).tolist() data = pd.DataFrame({'index': index, 'gender': gender, 'pet': pet}) data.head(10) index gender pet 0 0 male dog 1 0 male dog 2 0 male cat 3 0 female dog 4 0 female dog 5 0 female cat 6 1 male cat 7 1 male dog 8 1 male dog 9 1 female dog I want to make a 2x2 grid of 4 mosaic plots, each for the subset of column index.
Now, a single mosaic plot of say the first group (index == 0):
data0 = data[data['index'] == 0] props = {} for x in ['female', 'male']: for y, col in {'dog': 'red', 'cat': 'blue'}.items(): props[(x, y)] ={'color': col} mosaic(data0, ['gender', 'pet'], labelizer=lambda k: '', properties=props) plt.show()
But trying to put this mosaic in a custom function sns.FacetGrid.map() could use, I fail (this is one version, I tried a few):
def my_mosaic(sliced_data, **kwargs): mosaic(sliced_data, ['gender', 'pet'], labelizer=lambda k: '', properties=props) g = sns.FacetGrid(data, col='index', col_wrap=2) g = g.map(my_mosaic) --------------------------------------------------------------------------- TypeError Traceback (most recent call last) <ipython-input-323-a81a61aaeaff> in <module>() 5 6 g = sns.FacetGrid(data, col='index', col_wrap=2) ----> 7 g = g.map(my_mosaic) ~\AppData\Local\Programs\Python\Python36-32\lib\site-packages\seaborn\axisgrid.py in map(self, func, *args, **kwargs) 741 742 # Draw the plot --> 743 self._facet_plot(func, ax, plot_args, kwargs) 744 745 # Finalize the annotations and layout ~\AppData\Local\Programs\Python\Python36-32\lib\site-packages\seaborn\axisgrid.py in _facet_plot(self, func, ax, plot_args, plot_kwargs) 825 826 # Draw the plot --> 827 func(*plot_args, **plot_kwargs) 828 829 # Sort out the supporting information TypeError: my_mosaic() missing 1 required positional argument: 'sliced_data' I read the documentation and examples, but I just couldn't figure out how to make a callable function from any plotting function which isn't built-in in Seaborn or in matplotlib.pyplot (e.g. plt.scatter or sns.regplot).
1 Answer
I found it is easier to use map_dataframe() when you are ultimately dealing with... dataframes.
def my_mosaic(*args,**kwargs): mosaic(kwargs['data'], list(args), labelizer=lambda k: '', properties=props, ax=plt.gca()) g = sns.FacetGrid(data, col='index', col_wrap=2) g = g.map_dataframe(my_mosaic, 'gender', 'pet')
